IviCycle D1000

Multi-channel DC battery test system

Each channel: ±1A/-0.2 to +5V

19" rack-mountable housing

Low cost-per-channel battery test solution

Buy from your local reseller (US):

Nanoscience Instruments

Contact resellerRequest information

Product description

Dedicated battery test system

The IviCycle D1000 is designed to be your perfect partner for high channel-count battery applications. The IviCycle offers a low cost-per-channel, high volume testing solution and extensive data storage capability.

Complete solution

The IviCycle is a multi-channel DC battery test system. The channels are divided over 4 modules. It is possible to mix and match different IviCycle modules to create a custom-built instrument with the desired number of channels of varying compliance, and with DC only or EIS capability.

The D1000 modules each have 8 channels of ±1A/-0.2 to +5V compliance. The modules are available as DC versions only (no EIS). This means that simultaneous/parallel DC measurements are possible on all channels. The IviCycle has an integrated DataSecure module that stores all data for each channel completely independently from the computer. This ensures that if there is a communication loss or a computer crash/update, the measurement will continue and data will not be lost. This provides peace-of-mind for long duration, high throughput testing. The IviCycle unit is built into a 19inch rack mountable housing for easy incorporation into existing storage racks, or as a stand-alone bench-top multi-channel system.


The maximum current or potential of the instrument can be defined by the operator. Thus valuable samples may be protected, and unsafe situations prevented.

Data security & Connection

The IviCycle is equipped with an integrated DataSecure module:

  • Data is stored on board independent of the computer.
  • Connection of multiple PCs is possible


The IviCycle is controlled via Ivium’s own software, IviumSoft. This versatile, yet intuitive software, allows instrument control, data management and analysis, etc. The IviCycle can also be controlled from LabVIEWTM, C++, Delphi, etc. A full suite of software is included as standard with each instrument.

  • Control of separate channels individually
  • All channels simultaneously
  • Synchronous start
  • Data from different channels plotted individually or in 1 single graph
Read the full description


System performance
Current compliance
Maximum applied voltage
-0.2V to +5V
Electrode connections
4; WE, CE, RE, S with 4mm banana plugs
Potentiostat bandwidth
Signal acquisition
Dual channel 24bit ADC, 1,000 samples/s
Channel combination
Applied potential range
-0.2 to +5V, 0.15mV res.
Applied potential accuracy
0.2% or 1mV
Current ranges
±10µA to ±1A
Measured current resolution
0.00005% of current range, minimum 5pA
Measured current accuracy
0.025% of FSR
Applied current resolution
0.015% of applied current range
Applied current accuracy
Galvanostatic current ranges
±10µA to ±1A
Potential ranges
Measured potential resolution
Measured potential accuracy
0.2% or 1mV
Input impedance
>1000Gohm //<20pF
Input bias current
Peripheral connections
Analog in/out
16bit analog input available on cell connector, 1 per channel
Data Acquisition
Stored no. of datapoints
20M each channel
Power requirements
100-240V, 50-60Hz, 500VA
USB/LAN (Ethernet)
Size (w x d x h)
44 x 26 x 22cm
PC requirements
Windows 8/10/11, with free USB port
Integrated DataSecure
Stored no. of data points: 20M each channel
Specifications subject to change, Ivium Technologies ©2024
